DG47-00068A Range Oven Broil element
DG47-00068A Range Oven Broil Element
The DG47-00068A is a genuine OEM oven broil element for Samsung electric ranges and wall ovens. This broil element is the upper heating element positioned at the top of the oven cavity that provides direct high-temperature radiant heat for broiling food. The element is constructed from heavy-duty metal tubing (typically stainless steel or Incoloy alloy sheath) formed in a loop or coiled configuration, containing a high-resistance heating wire (nichrome alloy) embedded in ceramic or magnesium oxide insulation. The element measures approximately 16-18 inches wide x 14-16 inches deep with mounting brackets on each end and electrical terminals extending through the rear oven wall. The element operates at 240V AC and generates 4200 watts of heat, producing surface temperatures of 500-550Ā°F for effective broiling. The broil element mounts to the top of the oven cavity using mounting screws or brackets and connects to the oven's electrical system via wire terminals at the rear. When activated through the oven control (broil mode), electrical current flows through the nichrome heating wire, generating intense radiant heat through electrical resistance. This heat radiates downward onto food placed on the upper oven rack, creating the high-temperature searing and browning characteristic of broiling. Common failure causes include normal wear from age and thermal cycling, element burnout from electrical surge or overheating, physical damage from contact with cookware, corrosion from moisture or food spills, terminal connection failure, or manufacturing defects. When the broil element fails, symptoms include no heat during broil mode, uneven heating or hot spots, visible damage to element (blistering, breaks, or separation), element not glowing red when activated, burning smell, sparking or arcing, circuit breaker tripping, or error codes on control display. The DG47-00068A is a direct-fit replacement that restores full broiling functionality. CRITICAL: Always turn off power at the circuit breaker before working on electric ovens to prevent electrical shock from 240V AC. This is a moderate repair requiring removal of oven racks, disconnection of electrical terminals, and careful handling of the element. Test the old element with a multimeter to confirm failure before replacement.
Ā
Ā
Key Features & Design
- Heavy-Duty Construction: Built from robust materials to withstand regular use, providing longevity and resistance to wear for dependable operation.
- Power Specifications: Operates at 2,400 Watts and 230 Volts, delivering the precise heating required for effective broiling in compatible models.
- Compatibility: Specifically engineered to fit a wide range of Samsung oven models, including popular series like NE59J7630 and NE63T8711, making it a straightforward replacement option.
- Compact and Practical Design: Features a standard broil element form factor, as seen in its sleek, functional build, for easy installation in your existing oven setup.
Performance and Benefits
This broil element helps restore your oven's broiling function, solving issues like uneven heating or complete failure by providing steady, efficient warmth for better cooking results. Whether you're broiling meats or baking favorites, it enhances your kitchen experience with reliable performance, backed by XPart Supply Ltd.'s commitment to fast shipping and hassle-free returns, so you can maintain your appliances with confidence and minimal downtime.
The DG47-00068A Range Oven Broil Element is specifically designed to directly replace certain range oven's broil element. Constructed from heavy duty material, it is built to last and provide consistent and reliable performance. With a wattage of 2,400 Watts and a voltage of 230 Volts, this element provides powerful and efficient heating. Need your appliance repair parts right away we ship fast and offer a free return promise if you don't need it we will take it back no questions asked.
Supported Models:
NE59J7630SB/AA, NE59J7630SG/AANE59J7630SS/AA, NE59J7630SS/AC, NE59J7630SW/AA, NE59J7750WS/AA, NE59J7750WS/AC, NE59J7850WG/AA, NE59J7850WG/AC, NE59J7850WS/AA, NE59J7850WS/AC, NE59J7651WS/AC, NE59M6850SG/AA, NE59M6850SS/AA, NE59N6630SG/AA, NE59N6630SS/AA, NE59N6650SG/AA, NE59J7650WS/AA, NE59N6650SS/AA, NE63T8711SS/AA, NE63T8511SS/AA, NE63T8111SG/AA, NE63A6511SS/AA, NE63A6511SS/AC, NE63T8311SS/AA, NE59R6631SS/AA, NE59R6631SS/AC, NE59R6631SG/AA, NE59R6631SG/AC, NE59R6631ST/AA, NE63T8111SS/AA, NE63A6511SG/AA, NY63T8751SS/AA, NE63T8311SG/AA, NE63T8711ST/AA, NE63T8751SS/AA, NE63A6711SG/AA, NY63T8751SG/AA, NE63A6751SS/AA, NE63A6751SG/AA, NE63T8911SS/AA, NE63T8951SS/AA, NE63T8911SG/AA, NE63T8711SG/AA, NE63A8711QN/AA, NE63T8751SG/AA, NE63T8511ST/AA, NSE6DB830012AA, NE63B8211SS/AA, NSE6DG8300MTAA, NE63A6711ST/AA, NE63B8211SG/AA, NSE6DG8100SRAA, NE63B8611SS/AA, NE63B871112/AA, NE63BB871112AA, NSE6DB850012AA, NSI6DB950012AA, NSI6DB930012AA, NE63BB861112AA, NSE6DB870012AA, NE63BG8315SSAA, NSE6DG8500MTAA, NE63T8951SG/AA, NE63A6711SS/AA, NSE6DG8300SRAA, NE63B8611SG/AA, NSE6DG8700SRAA, DOP30T940DS/DA, NSE6DG8500SRAA, NSE6DG8100MTAA, NE63CB831512AA, NE63A6511SB/AA, NE63A6511SW/AA, NE63BB851112AA, NE63T8511SG/AA, NSI6DG9300SRAA, NSI6DG9100MTAA, NSI6DG9100SRAA, NSI6DG9500SRAA, NSI6DG9300MTAA, NSI6DB990012AA, NY63T8751SS/AC, NSI6DG9500MTAA, NSI6DG9900SRAA, NSY6DG8550SRAA, NSI6DG9550SRAA, NSE6DG8550SRAA, NSE6DG8502SRAA, NE63D6511SR/AA, NSE6DB850212AA, NE63D6711SR/AA, NSE6DG8502MTAA
