WP9755770 Range Bake Element (replaces 9755770, W10308474)

WP9755770 Range Bake Element

The WP9755770 is a genuine OEM oven bake element for Whirlpool, KitchenAid, Maytag, Jenn-Air, Amana, Kenmore, Inglis, and Magic Chef electric ranges and wall ovens. This bake element is the lower heating element positioned at the bottom of the oven cavity that provides the primary heat source for baking, roasting, and general cooking. The element is constructed from heavy-duty metal tubing (typically stainless steel or Incoloy alloy sheath) formed in a loop or horseshoe configuration, containing a high-resistance heating wire (nichrome alloy) embedded in ceramic or magnesium oxide insulation for electrical isolation and heat transfer. The element measures approximately 16-18 inches wide x 16-18 inches deep with mounting brackets and support arms, and electrical terminals extending through the rear oven wall. The element operates at 240V AC and generates 2600 watts of heat, producing surface temperatures of 450-500°F for effective baking and roasting. The bake element mounts to the bottom of the oven cavity using mounting screws or brackets and connects to the oven's electrical system via wire terminals at the rear. When activated through the oven control (bake mode), electrical current flows through the nichrome heating wire, generating heat through electrical resistance. This heat radiates upward and is distributed throughout the oven cavity by natural convection, creating the even heating environment required for baking. The element typically cycles on and off under control of the oven thermostat or electronic control board to maintain the selected temperature. Common failure causes include normal wear from age and thermal cycling (typically 10-15 years lifespan), element burnout from electrical surge or overheating, physical damage from contact with cookware or spills, corrosion from moisture or acidic food spills, terminal connection failure from arcing or loose connections, or manufacturing defects. When the bake element fails, symptoms include no heat during bake mode, oven not reaching set temperature, uneven heating or hot spots, visible damage to element (blistering, breaks, or separation), element not glowing red when activated, burning smell, sparking or arcing, circuit breaker tripping, or error codes on control display. The WP9755770 is a direct-fit replacement that restores full baking functionality. CRITICAL: Always turn off power at the circuit breaker before working on electric ovens to prevent electrical shock from 240V AC. This is a moderate repair requiring removal of oven racks, disconnection of electrical terminals, and careful handling of the element.

Key Features and Design

Durable Construction: Crafted with high-quality materials, this bake element is built to withstand daily use, offering long-lasting reliability for your oven's heating needs.
Exact Fit Compatibility: Replaces parts like 9755770 and W10308474, making it a perfect match for models such as AER6011VAW0, GERC4110PS0, and many others, ensuring seamless installation.
Compact 8-Inch Design: Engineered with an 8-inch insert for enhanced heat distribution, this element fits standard range ovens while maintaining a sleek, functional profile.

Performance and Benefits

This bake element revitalizes your oven by providing even and efficient heating, solving issues like uneven baking or incomplete cooking. From XPart Supply Ltd., it enhances your kitchen experience by restoring reliable functionality, saving you time and money on repairs while ensuring consistent results for everyday baking. Ideal for maintaining the performance of your electric range, this part helps extend the life of your appliance with its trustworthy design and easy integration.

The WP9755770 Range Bake Element has been designed to enhance cooking performance with its 8-inch insert. Perfect for countless baking tasks, it is built to last and offers reliable functionality.

Part number WP9755770 replaces 9755770, W10308474

Supported Models:
